Traxxas Maxx® Ultimate (Model #89087-4)

Scale: 1/10 | Drivetrain: Full-Time Shaft-Driven 4WD | Top Speed: 60+ MPH (with 4S LiPo and optional gearing)

Overview

The Traxxas Maxx Ultimate represents the peak of 1/10 scale monster truck performance, delivering durability, massive 4S brushless power, and factory-installed aluminum upgrades. Built to tackle the roughest terrain, the Maxx Ultimate takes the legendary Maxx platform and elevates it with premium handling and strength, making it the ultimate choice for extreme bashing.

Key Features & Highlights

Premium Aluminum Upgrades: Outfitted with anodized 6061-T6 aluminum C-hubs, steering blocks, rear hub carriers, transmission cover, and motor cradle, as well as 7075-T6 aluminum TUBES toe links and a double-shear servo horn.

Extreme 4S Velineon® Power: Features the Velineon 540XL brushless 2400 Kv motor paired with the VXL-4s™ waterproof speed control, delivering 55 MPH out of the box and 60+ MPH with optional gearing.

Clipless Body Mounting System: No clips, no hassle. One-handed installation and removal with a pivoting rear latch and internal reinforcements for maximum crash protection.

Ultra-Rugged Drivetrain: Features heavy-duty steel constant-velocity driveshafts, steel spur gear with Cush Drive™, splined aluminum center driveshaft, and large-module silicone fluid-filled differentials.

2085RL High-Output Steering Servo: A metal-gear, waterproof servo packing 650 oz-in of torque, coupled with aluminum bellcranks and a heavy-duty servo saver spring for lightning-fast, unyielding steering.

GT-Maxx® Aluminum Shocks: Large-bore, threaded aluminum shocks with TiN-coated shafts, aluminum caps, and double X-ring seal cartridges for superior damping and control.

TQi™ 2.4 GHz Radio with Wireless Module: Connects to the Traxxas Link app for real-time telemetry like speed, RPM, temperature, and battery voltage right on your smartphone.

Traxxas Stability Management® (TSM): Adjusts power and steering on loose or slippery surfaces to prevent spinouts, allowing you to punch the throttle with confidence.

WideMaxx® Stance: The pre-installed WideMaxx suspension kit extends the truck's track by over 1.5 inches for maximum cornering stability and aggressive handling.

Sledgehammer® Extreme Tires: Massive, pre-glued 2.8" black chrome wheels with rugged Sledgehammer treads for sure-footed grip and traction on dirt, mud, and gravel.

Technical Specifications

Length: 22.50 inches (572 mm)
Width: 15.95 inches (405 mm)
Wheelbase: 13.85 inches (352 mm)
Ground Clearance (Center): 2.60 inches (67 mm)
Weight: 10.20 lbs (4.63 kg)
Motor: Velineon® 540XL Brushless (2400 Kv)
ESC: Velineon® VXL-4s™ Waterproof ESC
Steering Servo: 2085RL Metal Gear Ultra-High-Torque

What's in the Box?

Fully assembled Traxxas Maxx® Ultimate Ready-To-Race® monster truck
TQi™ 2.4 GHz Radio System with Traxxas Link™ Wireless Module
Velineon® VXL-4s ESC & 540XL Brushless Motor
Quick Start Guide & high-quality maintenance tools

What You'll Need:

Battery: Single 3S or 4S LiPo Battery with Traxxas iD® connector (4S 14.8 V recommended)
Charger: Traxxas iD® Compatible LiPo Charger (EZ-Peak® Live Dual recommended).
Transmitter Batteries: 4 × AA Alkaline Batteries.
